Match the FHRP Protocols to the Appropriate Description

First Hop Redundancy Protocols (FHRP) are essential networking technologies that provide gateway redundancy for end‑hosts in a LAN environment. By allowing multiple routers to share a virtual IP address, FHRPs ensure continuous network connectivity even if the primary gateway fails. Understanding the characteristics of each protocol is crucial for network engineers preparing for certifications such as CCNA, CCNP, or for designing resilient enterprise networks. This article explains the most common FHRPs, outlines their key features, and provides a clear matching exercise so you can confidently associate each protocol with its correct description.

Overview of First Hop Redundancy Protocols

FHRPs operate at the data link layer (Layer 2) but influence Layer 3 routing by presenting a single virtual gateway to hosts. When the active router fails, a standby router takes over virtually instantaneously, minimizing downtime. The three most widely deployed FHRPs are:

• Hot Standby Router Protocol (HSRP) – Cisco proprietary
• Virtual Router Redundancy Protocol (VRRP) – Open standard (IETF RFC 3768)
• Gateway Load Balancing Protocol (GLBP) – Cisco proprietary, adds load‑balancing

Other less common protocols include CARP (Common Address Redundancy Protocol) used in BSD‑based systems and IRDP (ICMP Router Discovery Protocol), but the focus here is on the three main options because they dominate exam objectives and real‑world deployments.

Detailed Descriptions of Each FHRP

1. Hot Standby Router Protocol (HSRP)

• Vendor: Cisco (proprietary)
• Version: HSRPv1 (uses UDP port 1985) and HSRPv2 (supports IPv6, uses UDP port 1985 as well)
• Virtual MAC address format: 0000.0c07.acxx where xx is the group number in hexadecimal
• Active/Standby election: Based on priority (0‑255, default 100) and highest IP address as tie‑breaker
• Hello timers: Default 3 seconds hello, 10 seconds holdtime (can be adjusted)
• Preempt: Optional; allows a higher‑priority router to take over as active after recovery
• Tracking: Interface tracking can lower priority when a tracked interface goes down
• Load‑balancing: Not inherent; only one active router forwards traffic per group (though multiple groups can be used for basic load sharing)

2. Virtual Router Redundancy Protocol (VRRP)

• Vendor: Open standard (IETF) – supported by many vendors (Cisco, Juniper, Huawei, etc.)
• Version: VRRPv2 (IPv4) and VRRPv3 (IPv4/IPv6)
• Virtual MAC address format: 0000.5e00.01xx for VRRPv2, 0000.5e00.02xx for VRRPv3 (where xx is the VRID in hex)
• Active/Standby election: Based on priority (1‑254, default 100) and highest IP address as tie‑breaker; priority 255 reserved for the IP address owner
• Hello timers: Default 1 second advertisement interval (adjustable)
• Preempt: Enabled by default; can be disabled
• Tracking: Interface tracking supported (similar to HSRP)
• Load‑balancing: VRRP itself does not load‑balance; however, multiple VRRP groups can be configured to achieve basic load sharing

3. Gateway Load Balancing Protocol (GLBP)

• Vendor: Cisco (proprietary)
• Version: GLBPv1 (IPv4) – no IPv6 version as of the latest Cisco IOS releases
• Virtual MAC address format: 0007.b400.xxyy where xx is the GLBP group number and yy is the virtual forwarder (VF) number
• Active Virtual Gateway (AVG): One router elected as AVG (based on priority, then highest IP) – responsible for answering ARP requests for the virtual IP
• Virtual Forwarders (VFs): Up to four VFs per group; each VF receives a unique virtual MAC and forwards a portion of the traffic
• Load‑balancing methods: Round‑robin, host‑dependent, or weighted (based on configured weights) * Hello timers: Default 3 seconds hello, 10 seconds holdtime (adjustable)
• Preempt: Supported for both AVG and VF roles
• Tracking: Interface tracking can affect both AVG and VF priorities

Matching Exercise: Protocol ↔ Description

Below is a list of descriptive statements. Match each statement to the correct FHRP (HSRP, VRRP, or GLBP). After the list, you’ll find the answer key with brief explanations.

Answer Key
